Note: CADblocks for DraftSight was discontinued by its developer. Unfortunately this plug-in is therefore no longer available. To learn more about the Graebert plugins currently available for DraftSightwe invite you to visit https://www.graebert.com/cad-software/plugins-for-draftsight/ CAD Blocks for DraftSight 1 00:00:09,160 –> 00:00:13,680“CAD Blocks for DraftSight” gives you access to thousands of blocks. 200:00:14,000 –> 00:00:16,860Many of these blocks contain intelligence. 300:00:17,60 –> 00:00:21,259In this example, we can see an office where you find blocks for furniture, 400:00:21,460 –> 00:00:26,260sanitary equipment, various labels and signs. 500:00:27,60 –> 00:00:30,340They all belongto blocks supplied by CAD  Blocks. 600:00:31,220 –> 00:00:32,879The process is very simple. 700:00:33,220 –> 00:00:34,440We click here … 800:00:34,520 –> 00:00:40,820… go to the category we like, select with a click and look for the topic of our interest. 900:00:41,240 –> 00:00:44,300For example, we can insert this block. 1000:00:44,640 –> 00:00:50,920Here we have a larger preview, while in this area parameters will appear
