ARES Mechanical includes ready-to-use mechanical part-libraries such as: Bolts & Screws, Screw Connections, Nuts, Pins & Washers, Hole & Hole Table, Hole Callouts.

You will find these parts in the Toolbox ribbon of the Mechanical workspace. They are pre-configured and standardized based on the mechanical standard you have chosen for your project.

These smart entities will help you to speed up the design and make sure it is compliant with the chosen standard. They will also further be recognized for the creation of your BOM.

The Toolbox ribbon includes other mechanical features such as symbols for surface and welding; Balloons and Bill of Materials (BOM) and Revision Tables.

We created a dedicated user interface optimized for Mechanical Design with quick access to all the features you need. The Mechanical ribbon highlights  in the first tabs the top level features needed for a quick sketch of a new drawing.

In the Toolbox tab of this ribbon you will also find most of the mechanical features such as the part libraries, holes, screw connections, BOM, symbols and revision tables.

If you don’t like ribbons, the “Classic” workspace is replacing the ribbon by menus and toolbars.

All the features of ARES Commander remain also available. If you are not working on a mechanical project you may simply switch to the “Drafting and Annotation” workspace for 2D or to the “3D Modeling” one for 3D.

Advanced users may also simply use keyboard commands with any of these workspaces.

Easy switch to the Mechanical workspace optimized for Mechanical Design

In the Mechanical workspace you will find the Toolbox tab with all the Mechanical features

ARES Mechanical will automatically create the layers as your draw, based on the chosen standard and the entities you will use. Mechanical entities will therefore be grouped on specific layers as required by the standards.

Besides significant time-savings, it will unify the style of your drawings, and make sure they are standard-compliant. Nevertheless, you can further customize the predefined layer settings to adapt to your company needs and save your preferences.

Construction Lines (vertical, horizontal or at a defined angle) are easy to maintain, they are on a predefined layer and can be switched on or off as and when required. They are easy to pick and can be combined with our Power Trim feature to help you accelerate your design.

ARES Mechanical includes some other smart features such as rectangles with dimensions. This feature would let you draw a rectangle and automatically add dimensions.

Mechanical design conventions require that you use specific hatch patterns in the sections of your mechanical drawings. These hatch patterns help to standardize drawings and define the material of the elements.

You can now use Predefined hatches in your designs. Many commonly used hatch patterns are included, which can be further customized based on your requirements.
